RGBW DMX LED Dot

Name: RGBW DMX LED Dot
Brand: 3Cinno
SKU: 1659333

Send Inquiry

DMX Super Dot is designed for long lasting outdoor uses and excellent lighting effects.It delivers multiple color available in RGBW, White and RGB.Conforming to DMX512, you can daisy chain them up to 40 pieces in series.Longer than that length will take extra power supply to feed every 40 dots.Diffusers are available in clear flat and milky dome.Black substrate offers screw mounting holes for easy and quick installation.It is popular in use for special events,shows,architectural lighting projects,etc.

DMX 512

Run this fixture in any standard DMX interface.

RGB/WHITE/RGBW

3-in-1 RGB LED Pixel. Option color avaible in RGB+white, white(2600-6500K)

SCREW MOUNTING

Screw mounting holes on each corner of the 98*73mm(3.86*2.87") base.

MAX 40PCS IN SERIES

Daisy chain of 40 dots; Extra power feed for each 40 nodes in series.

DMX Super Dot

	3C-SP-1CH	3C-SP-3CH	3C-SP-4CH
LED QTY	12White	12RGB	6RGB+6White
Color	White	RGB	RGBW
Light Source	SMD5050
Beam Angle	120°
Voltage	DC12V/24V
Wattage	2.5W
Size	987365mm; 987350mm
Size	3.862.872.56"; 3.862.871.97"
Diffuser	Milky Dome; Clear Flat
Working Temperature	-40℃~80℃
IP Rating	IP67
Channels	1CH	3CH	4CH
Protocol	DMX512
Controller	Standard DMX Interface
DMX Addressability	Self Address/Manually
